s12 120 - Tech Specs
Finishing
Materials
Painted metal structure with pendants
Light source
Traditional:
12XE26X60W
Led 3000k:
UP: 15,6W CRI>95 3000K - 1536 nominal LM DOWN: 62,4W CRI>95 3000K - 6144 nominal LM
Led 2700k:
UP: 15,6W CRI>95 2700K - 1464 nominal LM DOWN: 62,4W CRI>95 2700K - 5856 nominal LM
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Led:
0-10 V
Dimensions
| H | 20 cm | 7.87'' |
|---|---|---|
| Ø | 120 cm | 47.24'' |
Certifications
Traditional Light:
Led Light:
s6 90 - Tech Specs
Finishing
Materials
Painted metal structure with pendants
Light source
Traditional:
8XE26X60W
Led 3000k:
UP: 10,4W CRI>95 3000K - 1024 nominal LM DOWN: 31,2W CRI>95 3000K - 3072 nominal LM
Led 2700k:
UP: 10,4W CRI>95 2700K - 976 nominal LM DOWN: 31,2W CRI>95 2700K - 2928 nominal LM
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Led:
0-10 V
Dimensions
| H | 20 cm | 7.87'' |
|---|---|---|
| Ø | 90 cm | 35.43'' |
Certifications
Traditional Light:
Led Light:
s6 60 - Tech Specs
Finishing
Materials
Painted metal structure with pendants
Light source
Traditional:
6XE26X60W
Led 3000k:
UP: 7,8W CRI>95 3000K - 768 nominal LM DOWN: 23,4W CRI>95 3000K - 2304 nominal LM
Led 2700k:
UP: 7,8W CRI>95 2700K - 732 nominal LM DOWN: 23,4W CRI>95 2700K - 2196 nominal LM
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Led:
0-10 V
Dimensions
| H | 20 cm | 7.87'' |
|---|---|---|
| Ø | 60 cm | 23.62'' |
Certifications
Traditional Light:
Led Light:
s6 40 - Tech Specs
Finishing
Materials
Painted metal structure with pendants
Light source
Traditional:
6XE12X40W
Led 3000k:
UP: 13,7W CRI>95 3000K - 1348 nominal LM DOWN: 13,7W CRI>95 3000K - 1348 nominal LM
Led 2700k:
UP: 13,7W CRI>95 2700K - 1285 nominal LM DOWN: 13,7W CRI>95 2700K - 1285 nominal LM
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Led:
0-10 V
Dimensions
| H | 20 cm | 7.87'' |
|---|---|---|
| Ø | 40 cm | 15.74'' |
Certifications
Traditional Light:
Led Light:
s2 15 - Tech Specs
Finishing
Materials
Painted metal structure with pendants
Light source
Traditional:
1xE12X40W
Led 3000k:
DOWN: 7,5W CRI>90 3000K - 1080 nominal LM
Led 2700k:
DOWN: 7,5W CRI>90 2700K - 1026 nominal LM
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Led:
TRIAC
Dimensions
| H | 26 cm | 10.23'' |
|---|---|---|
| Ø | 15 cm | 5.90'' |
Certifications
Traditional Light:
Led Light:
