OUT PL1 20 - Tech Specs
Finishing
Materials
Painted metal structure. Polyethylene diffusers.
Light source
Traditional:
1XE12X40W
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Dimensions
| H | 49 cm | 19.3'' |
|---|---|---|
| Ø | 20 cm | 7.9'' |
| D | 80 cm | 31.5'' |
Certifications
IP:
IP54Traditional Light:
OUT PL1 30 - Tech Specs
Finishing
Materials
Painted metal structure. Polyethylene diffusers.
Light source
Traditional:
1XE26X60W
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Dimensions
| H | 64 cm | 25.2'' |
|---|---|---|
| Ø | 30 cm | 11.8'' |
| D | 80 cm | 31.5'' |
Certifications
IP:
IP54Traditional Light:
OUT PL5 - Tech Specs
Finishing
Materials
Painted metal structure. Polyethylene diffusers.
Light source
Traditional:
5XE12X40W
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Dimensions
| H | 68 cm | 26.8'' |
|---|---|---|
| Ø | 85 cm | 33.5'' |
| D | 80 cm | 31.5'' |
Certifications
IP:
IP54Traditional Light:
OUT PL6 95 - Tech Specs
Finishing
Materials
Painted metal structure. Polyethylene diffusers.
Light source
Traditional:
6XE12X40W
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Dimensions
| H | 66.5 cm | 26.2'' |
|---|---|---|
| Ø | 94 cm | 37'' |
| D | 80 cm | 31.5'' |
Certifications
Traditional Light:
OUT PL8 RD 120 - Tech Specs
Finishing
Materials
Painted metal structure. Polyethylene diffusers.
Light source
Traditional:
8XE12X40W
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Dimensions
| H | 76.5 cm | 30.1'' |
|---|---|---|
| Ø | 120 cm | 47.2'' |
| D | 80 cm | 31.5'' |
Certifications
Traditional Light:
OUT PL8 RD 160 - Tech Specs
Finishing
Materials
Painted metal structure. Polyethylene diffusers.
Light source
Traditional:
8XE26X60W
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Dimensions
| H | 83.5 cm | 32.9'' |
|---|---|---|
| Ø | 167 cm | 65.7'' |
| D | 80 cm | 31.5'' |
Certifications
Traditional Light:
OUT PL4+4 RD 100 - Tech Specs
Finishing
Materials
Painted metal structure. Polyethylene diffusers.
Light source
Traditional:
8XE12X40W
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Dimensions
| H | 100 cm | 39.4'' |
|---|---|---|
| Ø | 100 cm | 39.4'' |
| D | 80 cm | 31.5'' |
Certifications
Traditional Light:
OUT PL5+5 RD 120 - Tech Specs
Finishing
Materials
Painted metal structure. Polyethylene diffusers.
Light source
Traditional:
10XE12X40W
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Dimensions
| H | 83.5 cm | 32.9'' |
|---|---|---|
| Ø | 120 cm | 47.2'' |
| D | 107 cm | 42.1'' |
Certifications
Traditional Light:
OUT PL8 OV 120 - Tech Specs
Finishing
Light source
Traditional:
8XE12X40W
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Dimensions
| H | 63.5 cm | 25'' |
|---|---|---|
| Ø | 120 cm | 47.2'' |
| D | 107 cm | 42.1'' |
Certifications
Traditional Light:
OUT PL8 OV 160 - Tech Specs
Finishing
Light source
Traditional:
8XE12X40W
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBS
Dimensions
| H | 63.5 cm | 25'' |
|---|---|---|
| Ø | 160 cm | 63'' |
| D | 107 cm | 42.1'' |
Certifications
Traditional Light:
